Geberit Mapress Stainless Steel Ball Valve With Actuator Lever, Flanged (15mm - 88.9mm)This Geberit Mapress ball valve with flanged connections and actuator lever provides reliable manual isolation within a pipework system. As part of the Geberit Mapress press-fit system, it delivers a fast, flame-free connection in seconds, with no soldering and no need for a hot-works permit. It is manufactured from CrNiMo stainless steel 1.4401 (EN 10088) for durability and corrosion resistance.
Engineered to the renowned Geberit press-fit standard, the fitting features an integral pressing indicator and is designed to leak if left unpressed, so any missed joint is easily identified during testing. The pressing socket is fitted with a transparent protection plug, and the joint is sealed with a CIIR seal ring.
Key features
- Spindle caulk made of PTFE
- Section seal of flange and ball made of PTFE
- Fulfils requirements in accordance with TA Air VDI 2440
- Connecting flange for motor in accordance with EN ISO 5211 (only for d = 76.1–108 mm)
- Length-adjustable actuator lever (only for d = 108 mm)
- Lockable
- Pressing indicator
- Leaky if unpressed
- Seal ring made of CIIR, black
- Pressing socket with transparent protection plug
Suitable for
- For cooling and heating water without antifreeze agent
- For cooling and heating water with antifreeze agent
- For district heating water ≤ 120 °C
- For service water and process water
- For treated water (application range according to Technical Information „Treated water“)
- For grey and black water with a pH value ≥ 5.5
- For extinguishing water (wet)
- For compressed air (oil purity class 0–3)
Available in a size range from 15mm to 88.9mm.
