The Geberit Mapress Stainless Steel offset elbow tap connector turns a Mapress Stainless Steel gas run through 90° and out onto a female BSP thread, offset from the pipe centre-line with two fixing points sized for a standard 50mm circular wall box — for mounting a gas meter or tap connection flush to a wall or panel.
Made in CrNiMo steel 1.4401 (EN 10088) and built specifically for the Mapress Stainless Steel gas range, it's fitted with a yellow HNBR seal ring — the gas-rated seal material — with a pressing indicator that shows at a glance whether the joint has been correctly pressed, and a yellow protection plug on the pressing socket to keep the seal clean until it's fitted.
Key features
- Pressing indicator confirms a completed press
- Leaky if unpressed, so a missed press is easy to spot before commissioning
- Marked in yellow, Mapress's colour coding for the gas range
- Two fastening points for circular hole ø 50 mm
- Seal ring made of HNBR, yellow
- Silicone-free (LABS-free)
- Pressing socket with yellow protection plug
Suitable for
- For natural gases
- For liquefied gases
- For biogases
- For connecting one- and two-pipe gas metres
- For natural and liquefied gases
Available in 28mm.
