Plasson 5 Port End Supply Manifold
The Plasson 5 Port End Supply Manifold splits an incoming water main into 5 separate metered supplies from a single 2" BSP male iron (MI) inlet, fitted at one end of the manifold, feeding the outlets in sequence along its length.
Each of the 5 outlets carries a 63mm spigot for connection to the Plasson MCP system, rated PN16 and suitable for SDR 11 to SDR 21 pipe. A drain-off cock accessory (sold separately) is available to fit the manifold for draining down the system.
Key specifications
- 5-port end-fed manifold
- 2" BSP male iron (MI) inlet
- 63mm outlet spigot per port
- Rated PN16
- Suitable for SDR 11 to SDR 21 pipe
Available in 90mm outlet centres.
