BSP Pressure Reducing Valve -25 Bar Inlet
LeengateSKU: 51.PRV.020.000
- WRAS approved
- PN25 pressure rated
BSP Pressure Reducing Valve -25 Bar Inlet
LeengateSKU: 51.PRV.020.000
View
Price:£88.92£74.10
£31.13(Inc. VAT)
£25.94(Exc. VAT)
Stock:In stock
Quantity:
1
Frequently bought together
Pickup available at Trade Counter - Treforest Industrial Estate
Usually ready in 4 hours
Description
Brass Pressure Reducing Valve – 25 Bar Inlet
This brass pressure reducing valve (PRV) is WRAS approved and is suitable for oil and water applications up to 80°C. The PRV comes with a ¼” BSPP female threaded outlet port, which can be screwed to a ½” BSPP male inlet port, with a maximum working pressure of 25 Bar. This PRV can be adjusted between a minimum outlet pressure of 0.5 Bar and maximum pressure of 6.0 bar by using the adjustment collar on the side of the body.
Summary
Specification
Body
Brass
Internal
Brass
Seat
Stainless Steel
Stem
Brass CW614 N UNI EN 12164
O-rings
NBR/FP75N
Flat Gaskets
Fasit
Plastic Parts
Ultramid A3K
This brass pressure reducing valve (PRV) is WRAS approved and is suitable for oil and water applications up to 80°C. The PRV comes with a ¼” BSPP female threaded outlet port, which can be screwed to a ½” BSPP male inlet port, with a maximum working pressure of 25 Bar. This PRV can be adjusted between a minimum outlet pressure of 0.5 Bar and maximum pressure of 6.0 bar by using the adjustment collar on the side of the body.
Summary
- Pressure Reducing Valve
- Brass body
- Union, Screwed and Compression End connections
- Sizes: 1/2" to 2" and 22mm
- Adjustable outlet pressure of 0.5 to 6 Bar (1/2" to 1")
- Adjustable outlet pressure of 1.5 to 6Bar (1 1/4" to 4")
Specification
Body
Brass
Internal
Brass
Seat
Stainless Steel
Stem
Brass CW614 N UNI EN 12164
O-rings
NBR/FP75N
Flat Gaskets
Fasit
Plastic Parts
Ultramid A3K
